Banana Pi BPI-M4 Zero
Banana Pi BPI-M4 Zero is the successor model of M2 Zero. It has a huge improvement in performance. The SOC is upgraded to H618 and the CPU frequency is increased by 25%. The memory is upgraded to DDR4, the capacity is quadrupled, and 8G eMMC is added. It supports 5G WiFi, and the USB interface has also been upgraded to type-C.
It has the same form factor and 40-pin connector as the Raspberry Pi Zero W, and it will fit most Zero W cases and accessories.
Allwinner H618, Quad-core ARM Cortex™-A53 processor
ARM Mali G31 GPU
2G LPDDR4 RAM
8G eMMC flash memory
2.4G/5G WIFI & Bluetooth 4.2
1x USB2.0 Type-C OTG,, 1x USB2.0 Type-C
Banana Pi BPI-M4 Zero is the successor model of M2 Zero. It has a huge improvement in performance. The SOC is upgraded to H618 and the CPU frequency is increased by 25%. The memory is upgraded to DDR4, the capacity is quadrupled, and 8G eMMC is added. It supports 5G WiFi, and the USB interface has also been upgraded to type-C.
It has the same form factor and 40-pin connector as the Raspberry Pi Zero W, and it will fit most Zero W cases and accessories.
-
Key Features
- Allwinner H618, Quad-core ARM Cortex™-A53 processor
- ARM Mali G31 GPU
- 2.4G/5G WIFI & Bluetooth 4.2
- 2G LPDDR4 RAM
- 8G eMMC flash memory
- 1x USB2.0 Type-C OTG, 5V power supply
- 1x USB2.0 Type-C
- 1x miniHDMI 2.0a
- 1x 24-pin FPC connector
- 1x USB2.0
- 1x 100Mbps Ethernet
| ardware Specification of Banana pi BPI-M4 Zero | |
| CPU | Allwinner H618, Quad-core ARM Cortex™-A53 processor, 64-bit, up to 1.5GHz |
| GPU | ARM Mali G31 GPU |
| Memory | 2 GB LPDDR4 |
| Storage | 8G eMMC flash |
| SD card | MicroSD card slot, SDIO3.0 |
| Wireless | 2.4G/5G WiFi and Bluetooth 4.2 |
| HDMI | 1x miniHDMI 2.0a (up to 4K@60Hz with HDR10, CEC, DDC, SCDC), HDMI digital Audio output |
| USB | 1x USB2.0 Type-C HOST, 1x USB2.0 Type-C OTG |
| 40-pin header | 28 pins GPIO and Power (+5V, +3.3V and GND) |
| UART, SPI, TWI/I²C, PWM, PCM/I²S | |
| 24-pin FPC | 0.5mm pitch FPC connector， 1x USB2.0, 1x IR, 1x 100Mbps Ethernet |
| 9 pins GPIO, UART,TWI/I²C, PWM, PCM/I²S | |
| Buttons | Reset, FEL |
| LED | Power Status and Activity status |
| Power | 5V@3A via USB Type-C |
| Size | 65mm × 30mm |
24-pin FPC
| 24-pin FPC define and GPIO Alternative Functions Assignments | |||||
| Pin Num | Pin Name | ALT0 | ALT1 | ||
|---|---|---|---|---|---|
| 1 | GND | ||||
| 2 | EPHY_RXN | ||||
| 3 | EPHY_RXP | ||||
| 4 | EPHY_TXN | ||||
| 5 | EPHY_TXP | ||||
| 6 | GND | ||||
| 7 | PI9 | UART3_TX | TWI2_SCK | ||
| 8 | PI10 | UART3_RX | TWI2_SDA | ||
| 9 | PI12 | UART3_CTS | PWM2 | ||
| 10 | PI11 | UART3_RTS | PWM1 | ||
| 11 | 3V3 | ||||
| 12 | 3V3 | ||||
| 13 | PI4 | H_I2S0_DIN0 | H_I2S0_DOUT1 | ||
| 14 | PI3 | H_I2S0_DOUT0 | H_I2S0_DIN1 | ||
| 15 | PI2 | H_I2S0_LRCK | |||
| 16 | PI1 | H_I2S0_BCLK | |||
| 17 | PI0 | H_I2S0_MCLK | |||
| 18 | GND | ||||
| 19 | PH10 | IR_RX | |||
| 20 | 5V | ||||
| 21 | 5V | ||||
| 22 | USB2_DP | ||||
| 23 | USB2_DM | ||||
| 24 | GND | ||||
